Honda Sportrax 90

DESIGNED FOR
KIDS

Riding made easy.

This tough, off road bike is a great introduction to riding ATVs. It comes with lots of great features to make riding easy, comfortable and fun.

Engine

86cc

OHV air-cooled engine

Purpose

Leisure

Drive

2WD

Starter

Key start

Electric

The right start

The Sportrax’s 86cc SOHC four-stroke engine offers smooth power delivery and legendary reliability. In combination with a maintenance-free CD ignition system and a 15mm carburetor, it offers excellent fuel economy and crisp throttle response.

Difference in detail

It’s Honda’s careful attention to detail that sets our ATVs apart from the rest.

Suspension

Independent front suspension features a pair of rugged shock absorbers.

Low seat height

Comfortably low 660,4mm seat height.

Proportions

Front brake lever positioned closer to grip to fit a wide variety of riders.

Exhaust and muffler

Exhaust and muffler are stainless steel for long-term durability.

Brakes and tires

Long-lasting front and rear sealed drum brakes and 203,2mm front and rear tires.

Comfort

Well-padded seat and single-shock rear suspension offers a high level of rider comfort.

Specifications

Classification Junior / Fun ATV
Engine 86cc air-cooled, wet-sump, transverse mounted SOHC 4-stroke single cylinder
Carburation Piston valve, 16mm throttle-body
Ignition CDI
Starter Key start electric
Transmission Four-speed manual shift, automatic clutch
Drive 2wd O-ring sealed chain
Power Steering No
Front Suspension Independent double wishbone 66mm travel
Rear Suspension Swingarm with single shock 66mm (2.6”) travel
Front Brakes 110mm dual, sealed mechanical drums
Rear Brake 140mm sealed mechanical drum
Front tyres 20 x 7-8
Rear tyres 19 x 8-8
Fuel Capacity (l) 6.3L, incl. 1L reserve
Bore x Stroke (mm) 47 × 49,5
Dimensions – Length (mm) 1489
Dimensions – Width (mm) 895
Dimensions – Height (mm) 928
Wheelbase (mm) 983
Seat Height (mm) 660
Ground Clearance (mm) 100
Towing Capacity (kg)
Front Rack Capacity (kg)
Rear Rack Capacity (kg)
